Types of Architectural Drawings and Their Purposes
Share this article
Key takeaways
- An architectural drawing is a technical drawing of a building project, and a complete set combines nine drawing types because each answers a different question about the same building.
- Architectural drawings communicate the design; construction drawings add the detail a contractor needs to price and build, and typically serve as contract documents.
- Read a set in order: title block, drawing index, site plan, floor plans, elevations and sections, legend and notes, then written dimensions.
- Sets are built in phases (schematic design, design development, construction documents), and the registered professional on the project signs and seals what goes to permit.

Architectural drawings are technical drawings of a building or building project. Together they show what a building is, where things go, how it sits on its site, and how it gets built. Clients use them to approve a design, authorities use them to review it, and contractors use them to price and build it.
No single drawing does all of that, so a project uses a set. This guide covers the types of architectural drawings and the question each one answers, how architectural drawings differ from construction drawings, what a full set includes and the order it is produced in, how to read one, and who draws it.
What Is Architectural Drawing?
An architectural drawing is a technical illustration that conveys the design, dimensions, materials, and layout of a building. It lets everyone see the structure before it exists and guides the people who build it. The common vocabulary is simple: people say plans, drawings, blueprints, or a set of plans, and professionals name each sheet by its view (floor plan, elevation, section, and so on).
In professional practice it is both a creative and a technical tool. Some drawings are conceptual and exist to explain an idea. Others are detailed enough to carry legal and regulatory weight. A complete set can include site plans, floor plans, elevations, sections, and details, among others.
The standard views are described the same way across references: a floor plan is a horizontal section cut through a building, an elevation is a view of one side of it as a flat representation, a cross section is a vertical plane cut through it, and a site plan shows the whole context of a building or group of buildings. Wikipedia’s entry on architectural drawing lists them if you want a quick overview.
1. Floor Plans
Floor plans are arguably the most recognized architectural drawings. They show the layout of rooms, walls, doors, and windows from a top-down perspective. Technically a plan is a horizontal section cut through the building, conventionally at about four feet above the floor, which is why windows and door swings show up in it.
Question it answers: Where is everything, and how do people move through it?
Who uses it: Clients, designers, contractors, and plan reviewers.
Purpose:
Provide a spatial overview
Guide interior layout and furniture arrangement
Communicate room functions
These are critical in residential, commercial, and industrial projects.
2. Elevations
Elevations represent the exterior or interior vertical surfaces of a building. They show a view of the building from one side, as a flat representation of one façade, or how a particular interior wall will look from the front.
Question it answers: What does it look like from here, and what is it made of?
Who uses it: Clients approving the look, and builders ordering and placing materials.
Purpose:
Showcase façade aesthetics
Define external materials and finishes
Indicate window and door placement
Learn how to cut labor costs while hiring the best talent in 2026
Download our FREE guide to learn how!
3. Sections
Sections are like vertical slices through a building. They reveal what a structure looks like internally, showing relationships between floors, ceiling heights, and materials. A wall section is the version that shows how a wall is assembled from foundation to roof.
Question it answers: How do the floors stack, and how do the parts meet?
Who uses it: Structural and MEP coordinators, and the crews framing and finishing the building.
Purpose:
Reveal structural relationships
Illustrate building composition
Clarify ceiling and floor levels
4. Site Plans
Site plans show the building in relation to its surroundings. They include elements such as topography, trees, pathways, driveways, and adjacent buildings, and a plan reviewer typically asks for a site plan that shows, among other things, the distance from the building to the lot lines.
Question it answers: Where does the building sit on its plot, and what is around it?
Who uses it: Owners, civil and landscape consultants, and the local building department.
Purpose:
Determine placement of the building on the site
Plan landscaping and outdoor elements
Ensure compliance with zoning regulations
5. Detail Drawings
These are zoomed-in views of specific construction elements like wall junctions, staircases, or window details. They show a small part of the construction at a larger scale, with measurements, materials, and assembly methods.
Question it answers: Exactly how is this junction built?
Who uses it: The contractor and the trades doing the work.
Purpose:
Clarify complex construction details
Support contractors in accurate execution
Prevent construction errors

6. Perspective Drawings
Perspective or 3D architecture drawing illustrations are used to visually communicate design intent. Isometric and axonometric projections belong to the same family. These are especially helpful in client presentations, because most clients cannot read a plan the way a designer does.
Question it answers: What will it feel like to stand there?
Who uses it: Clients, marketing teams, and design reviewers.
Purpose:
Aid in client understanding
Market and promote projects
Communicate design aesthetics
7. Reflected Ceiling Plans
These drawings show the ceiling layout as if viewed from the floor looking up, detailing lighting, HVAC systems, and ceiling finishes.
Question it answers: What is on the ceiling, and where exactly?
Who uses it: Interior designers, electricians, and HVAC installers.
Purpose:
Coordinate lighting and ceiling design
Communicate fixture placement
Guide interior detailing
8. Mechanical, Electrical, and Plumbing (MEP) Drawings
Though not always created by architects, MEP drawings are coordinated with architectural drawings to ensure systems integration. In the U.S. National CAD Standard’s sheet numbering, they get their own discipline letters (M, E, P) next to the architectural sheets.
Question it answers: How do air, power, and water get through the building without hitting anything else?
Who uses it: Engineers, the architect coordinating them, and the installing trades.
Purpose:
Coordinate HVAC, electrical, and plumbing systems
Prevent clashes with architectural elements
Ensure building functionality
9. As-Built Drawings
As-built drawings are created after construction to reflect what was actually built, including modifications from the original plans.
Question it answers: What is really in the building now?
Who uses it: Owners, facility managers, and the team planning a future renovation.
Purpose:
Record final project specifications
Support maintenance and future renovations
Provide legal and regulatory documentation
10. Schematic Designs vs. Construction Documents
Schematic designs are early-stage drawings meant to explore ideas and get client approval. Construction documents are the detailed set a contractor can price and build from. Schematic work is about the idea: spatial relationships, scale, and form for the owner to review. Construction documents are about execution: every dimension, detail, and note a contractor needs. The stages after them are covered below.
Architectural Drawings vs. Construction Drawings
The two terms overlap, and people use them loosely. A useful way to separate them is by what the drawing is for. One industry guide from an architecture studio puts it this way: architectural drawings focus on the design, layout, and aesthetics of a building and communicate it to clients, planners, and authorities, while construction drawings provide the detailed technical information contractors and builders need, and typically serve as contract documents.
In practice, think of it as design versus execution. Architectural drawings answer “is this the right building?” Construction drawings answer “can someone build and price exactly this, with no guessing on site?” The same plan, elevation, and section views appear in both. What changes is the amount of dimensioning, notation, and detail, and who has to coordinate them: construction drawings are created by architects working with engineers and technical draftsmen.
That is also why construction documents are the production heavy part of the job. Our note on what nearshore Revit drafting support covers breaks down the tasks involved.
What a Full Set Includes and the Order It Is Produced In
A set grows in phases. The AIA describes the usual sequence in a 2007 best practice document, and it states that the deliverables it lists are examples of common deliverables, not requirements, so your contract may define them differently. With that in mind, this is what each phase often produces:
- Schematic design: often a site plan, floor plans, sections, an elevation, and illustrative material such as renderings or models, with overall dimensions.
- Design development: floor plans, sections, and elevations with full dimensions, plus door and window details and an outline of material specifications. This is where the mechanical, electrical, plumbing, structural, and architectural details get laid out.
- Construction documents: a set of drawings with all the information the contractor needs to price and build the project. Bidding or negotiation and construction phase services follow.
Permit review is the point where a plan reviewer checks the set. A reviewer typically asks for complete architectural and structural plans, a site plan, and general specifications. ICC’s plan review checklist also notes that construction documents should be signed, sealed, and dated by the registered design professional under the registration laws of the state where the project will be built. That signature belongs to the architect or engineer of record on your project, not to whoever drafted the sheets.
A planning note if you are budgeting a set: what makes the effort vary is the building type, how many disciplines are involved, how far the drawings must go before bidding, how many revisions the client and reviewers request, and whether the work is delivered in a BIM model or in 2D CAD. We do not publish a figure here because those variables move it more than any average would.
How to Read a Set of Architectural Drawings
Do not start on the first floor plan. Read the set in the order the information is organized, and you will find most answers before you go looking:
- Title block. Check the project name, sheet title and number, scale, issue date, and revision on every sheet you open.
- Drawing index. The cover or first sheets list every sheet, so you can see what exists before hunting for it.
- Site plan. Orient yourself first: where the building sits, the lot lines, access, and neighbors.
- Floor plans. Learn the layout, then note the callouts that point to elevations, sections, and details.
- Elevations and sections. Follow those callouts to see heights, finishes, and how the parts stack.
- Symbols, notes, and legends. Read the legend before interpreting any symbol, because projects can use different graphic standards.
- Dimensions. Use the written dimensions. Never estimate by measuring the printout.
Common Scales and Sheet Numbers
Every drawing is made at a stated scale, and the scale tells you how much detail to expect. Typical imperial scales from a college drawing-standards guide, as used by many U.S. offices (they vary by office and project):
- 1/8" = 1'-0": commercial building plans, elevations, and building sections.
- 1/4" = 1'-0": house plans, elevations, and building sections.
- 1/2" = 1'-0": kitchen and bath plans and elevations.
- 3/4" = 1'-0": wall sections.
- 1 1/2" = 1'-0": building details.
- 1" = 1'-0": millwork details.
Those figures come from a drawing-standards handout used in a City Tech course, not from a code, so treat them as typical rather than required. The same guide gives metric equivalents for the common ones (for example 1:50 for house plans and 1:100 for commercial plans).
Sheet numbers follow a pattern too. Under the U.S. National CAD Standard’s Uniform Drawing System, a sheet identifier combines a discipline letter, a one digit sheet type, and a two digit sequence number. So A-101 reads as Architectural (A), a plan (type 1), first sheet in the sequence (01). Other disciplines use their own letters, for example S for structural, M for mechanical, E for electrical, and P for plumbing. Types run from general sheets (0) through plans (1), elevations (2), sections (3), large scale views (4), details (5), schedules and diagrams (6), and 3D representations (9). Firms adapt the system, and the open file we checked is from version 6 of the standard, so confirm your project’s convention in its drawing index.

Can You Draw Your Own Architectural Plans?
Sometimes. Whether an owner can draw their own plans, and whether those plans need a licensed professional’s seal, depends on the state, the municipality, and the type of building. Licensing is set by jurisdiction (NCARB lists licensing requirements by jurisdiction), so the reliable first step is to ask your local building department what it will accept for your project.
Who Produces the Set, and Where Remote Help Fits
The architect leads the design and owns the decisions. Drafters and BIM technicians turn those decisions into sheets: they build the model, extract plans, elevations, and sections, and keep details, schedules, and sheet numbers consistent. Engineers produce their own disciplines, and the architect coordinates them.
The load can be uneven. When several projects reach construction documents at the same time, a studio can run out of hands. If you are weighing a dedicated hire against overflow help, start with how many weeks a quarter your team is over capacity, then read when the bottleneck is technique and when it is capacity.
We place remote Revit and CAD professionals from global talent who integrate with your team and work in close time zones, and we take responsibility for the match: if it does not work, we replace the professional within two weeks. Your firm keeps the drawings’ design authority, the seal, and the permit submission. If you want to see how that covers a set, start with our construction documentation services.

Sources
- Wikipedia, Architectural drawing: definition of the term and the standard views.
- AIA, Defining the Architect’s Basic Services (best practice document, 2007): what schematic design, design development, and construction documents commonly produce.
- ICC, Plan Review Services: Construction Documents: documents requested for a building plan review and who signs and seals them.
- U.S. National CAD Standard, Uniform Drawing System (module 1): sheet identifier format, discipline letters, and sheet types.
- CUNY City Tech, Drawing standards handout: typical architectural scales and what each is used for.
- Plan7 Architecture, construction drawings vs. architectural drawings: one studio’s view of how the two sets differ.
- NCARB: lists architect licensing requirements by jurisdiction.
Frequently asked questions
Quick answers about what architectural drawings are, which types make up a set, how they differ from construction drawings, and how to read them.
What is an architectural drawing?
An architectural drawing is a technical drawing of a building or building project. It communicates the design, dimensions, materials, and layout of a building, lets everyone see the structure before it exists, and guides the people who build it. Some drawings are conceptual; others are detailed and carry legal and regulatory weight.
What are the main types of architectural drawings, and what are they called?
Floor plans, elevations, sections, site plans, detail drawings, perspective drawings, reflected ceiling plans, mechanical, electrical, and plumbing (MEP) drawings, and as-built drawings. In everyday speech people also say plans, blueprints, or a set of plans. A complete set uses several together, because each one answers a different question about the same building.
What is the difference between a floor plan and an elevation?
A floor plan is a top-down view showing the layout of rooms, walls, doors, and windows. An elevation is a straight-on view of a vertical surface, showing how the building looks from outside or how a specific wall reads from the front. One answers where things are, the other answers what they look like.
What is the difference between architectural drawings and construction drawings?
Architectural drawings focus on the design, layout, and look of a building and communicate it to clients and authorities. Construction drawings add the technical detail a contractor needs to price and build, and they typically serve as contract documents. Both use the same views; the difference is the level of detail and what the drawing is for.
How do you read a set of architectural drawings?
Start with the title block and the drawing index, then read the site plan, the floor plans, and the elevations and sections. Check the legend and notes before interpreting symbols, and use the written dimensions instead of measuring the printout.
Can I draw my own architectural plans?
It depends on your state, your municipality, and the type of building. Some jurisdictions accept owner prepared plans for certain projects and others require a licensed professional’s seal. Ask your local building department what it accepts before you start.
What is the average cost for architectural drawings?
There is no useful single average, because the cost depends on the building type, how many disciplines are involved, how far the drawings must go before bidding, how many revisions are requested, and whether the work is done in BIM or 2D CAD. Get a scope based quote from the professional who will be responsible for the set.
