F8 toggles Ortho, F3 toggles Object Snap, F10 toggles Polar Tracking and F12 toggles Dynamic Input. This is the full list from the video, what each key does, and where two of them conflict.

Your mouse is the slowest tool in AutoCAD. Four keys fix that.

Dragging a line into place with the mouse carries a small amount of guesswork every time: a corner that looks closed but has a hairline gap, a wall that looks straight but is a fraction of a degree off, a point that should land on an existing intersection but lands a pixel away instead. Four default AutoCAD function keys fix exactly this, without changing the mouse or the workflow around it: F8 (Ortho), F3 (Object Snap), F10 (Polar Tracking) and F12 (Dynamic Input). This is the complete list promised for commenting SHORTCUTS: what each one does, and where two of them conflict.

All four are documented in Autodesk's own AutoCAD function key reference, not a custom setup.

F8 (Ortho): restrict the cursor to straight lines

F8 toggles Ortho mode. With it on, the cursor can only move horizontally or vertically relative to the current coordinate system, so a line drawn with the mouse comes out exactly straight instead of close to straight, a behavior Autodesk documents in its function key reference. Press F8 again to turn it off when you need to draw at a free angle. It is the fastest fix for the single most common mouse error: a wall, a center line or a dimension that looks straight on screen but carries a fraction of a degree of drift that only shows up later, in a section or a schedule.

F3 (Object Snap): snap to points that already exist

F3 toggles Object Snap, usually shortened to Osnap, also listed in Autodesk's function key reference. With it on, the cursor snaps to specific points on existing geometry (endpoints, midpoints, centers, intersections, perpendiculars) instead of to wherever the mouse happens to be hovering. A new line that is supposed to start exactly where an existing wall ends will actually start there, to the point, instead of a pixel or two off. Which snap points are active (endpoint, midpoint, center and so on) is set separately in AutoCAD's Object Snap settings; F3 only turns the whole mode on or off.

F10 (Polar Tracking): set an angle once, keep drawing straight

F10 toggles Polar Tracking, per Autodesk's function key reference. It works like Ortho, but for angles you choose instead of only horizontal and vertical: set the angle once, and a guide line appears as the cursor nears a multiple of that angle, so the line snaps straight to it. It is the tool for diagonal walls, angled site lines or any geometry that is not a simple right angle, which Ortho cannot help with at all.

The one conflict: Ortho and Polar Tracking turn each other off

Ortho (F8) and Polar Tracking (F10) are mutually exclusive in AutoCAD, as Autodesk's own function key reference documents: turning one on automatically turns the other off. That is expected behavior, not a bug. In practice it means picking the one that matches the geometry in front of you: Ortho for horizontal and vertical work, Polar Tracking the moment an angle other than 90 degrees shows up, and switching back with a single key press when the geometry changes again.

F12 (Dynamic Input): read coordinates at the cursor, not the command line

F12 toggles Dynamic Input, the fourth key in Autodesk's function key reference. With it on, AutoCAD shows the current coordinates, distance and command prompts in a small box that follows the cursor, so a distance or an angle can be typed right where you are looking instead of down in the command line at the bottom of the screen. It does not change what any command does; it changes where you read and type while a command is running, which is most of the benefit when a line or an offset needs an exact number typed in mid-draw.

When a function key does nothing at all

If a function key seems to do nothing, the keyboard itself is the usual cause, not AutoCAD. Autodesk's own support article on this exact issue explains that many keyboards ship with the function key row defaulting to multimedia controls (volume, brightness, playback) instead of standard function keys, so F8 adjusts the volume instead of toggling Ortho. Holding the Fn key while pressing the function key fixes it for that one press; most keyboards also have a permanent switch (a key combination or a setting in the keyboard's own software) to put the whole row back into function key mode.

These four are a start, not the whole list

AutoCAD has twelve function keys in total, F1 through F12, plus hundreds of other shortcuts and command aliases beyond them. These four, Ortho, Object Snap, Polar Tracking and Dynamic Input, are the ones that most directly replace the mouse's guesswork when placing or correcting a line. The full AutoCAD shortcut sheet has the complete set sourced from Autodesk's own 2024 shortcuts guide, organized by category and searchable in one field, including these same four keys documented against Autodesk's reference. For a related four-key list from the same kind of video, see the four AutoCAD layer commands that skip the Layer Properties list the same way these four skip dragging.
